Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in manufacturing construction machinery. They produce equipment such as manlifts, boom lifts and aerial lifts. These types of equipments are designed to facilitate access to hard to reach places, buildings and roofs, large equipment, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also known as OSHA refers to a power-driven endless belt. This belt only moves in one direction and contains platforms, or steps or handholds that are attached to the unit in order to move personnel from every floor.
TB85
The Terex TB85 provides a maximum working height of 91 feet. Furthermore, the maximum height of the platform reaches 85 feet. The maximum width of this model is 8 feet, 1 and 1/2 inches. The TB85 has dimensions which measure 9 feet, 1-inch high and 9 inches wide by 36 feet. This particular model provides a reach of 70 feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal measuring 75 degrees.
Terex TB100
The Terex TB100 man lift's maximum height is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is roughly 9 feet high by 8.5 feet wide by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, while the max working height measures at 116 feet. The model is 8 feet wide x 9 feet, 4 inches high The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This particular model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
